- With standard equipment
- With safety pack
Ulteriori informazioni nella sezione Commenti generali della valutazione
Ulteriori informazioni nella scheda Validità della valutazione
- See More
- See More
- See More
- See More
- Buona
- Adeguata
- Marginale
- Scarsa
- Insufficiente








- Buona
- Adeguata
- Marginale
- Scarsa
- Insufficiente


Passeggero
laterale
Centro
Montato di serie sul veicolo
Non montato sul veicolo di prova, ma disponibile come opzione
Non disponibile
-
i-Size
-
ISOFIX
-
Sistema di ritenuta con ancoraggio a cinture di sicurezza universali
Installazione senza problemi
Installazione accurata
Problema per la sicurezza
Installazione non consentita
Sedile | ||||
---|---|---|---|---|
Anteriore | 2a fila | |||
Passeggero | Sinistra | Centro | Destra | |
Maxi Cosi 2way Pearl & 2wayFix (rearward) (iSize) | ||||
Maxi Cosi 2way Pearl & 2wayFix (forward) (iSize) | ||||
BeSafe iZi Kid X2 i-Size (iSize) | ||||
Maxi Cosi Cabriofix & FamilyFix (ISOFIX) | ||||
BeSafe iZi Kid X4 ISOfix (ISOFIX) | ||||
Britax Römer Duo Plus (ISOFIX) | ||||
Britax Römer KidFix XP (ISOFIX) | ||||
Maxi Cosi Cabriofix (Belt) | ||||
Maxi Cosi Cabriofix & EasyBase2 (Belt) | ||||
Britax Römer King II LS (Belt) | ||||
Britax Römer KidFix XP (Belt) |
Installazione senza problemi
Installazione accurata
Problema per la sicurezza
Installazione non consentita
In the frontal offset test, protection of the 6 year dummy was good for all critical body regions. Protection of the neck of the 10 year dummy was marginal but that of other body areas was good. In the side barrier test, protection of all critical body areas was good for both dummies, and maximum points were scored. The front passenger airbag can be disabled to allow a rearward-facing child restraint to be used in that seating position. Clear information is provided to the driver regarding the status of the airbag and the system was rewarded. All of the restraint types for which the Q5 is designed could be properly installed and accommodated in the vehicle.
- Buona
- Adeguata
- Marginale
- Scarsa
- Insufficiente

Impatto testa 17,6 Pt
Impatto bacino 2,6 Pt
Impatto gambe 5,0 Pt
Nome sistema | Audi PreSense City | |||
Tipo | Auto-Brake with Forward Collision Warning | |||
Operativo da | 10 Km/h | |||
Ulteriori informazioni | Defaults on for every journey; operates above 40km/h and in low ambient light | |||
Evitamento | Mitigazione | |||
Adulto che cammina in attraversamento da parte opposta
|
Collisione evitata fino a 60 km/h | |||
Adulto che cammina in attraversamento dal lato marciapiede -25%
|
Collisione evitata fino a 40 km/h | Collisione mitigata fino a 60 km/h | ||
Adulto che cammina in attraversamento dal lato marciapiede -75%
|
Collisione evitata fino a 50 km/h | Collisione mitigata fino a 60 km/h | ||
Bambino che proviene in corsa da veicoli parcheggiati
|
Collisione evitata fino a 40 km/h | Collisione mitigata fino a 55 km/h |
The Q5 has an 'active' bonnet. Sensors detect when a pedestrian has been struck and actuators lift the bonnet to provide greater clearance between its top surface and hard structures in the engine bay. Audi showed that the system worked robustly for several pedestrian statures and over a wide range of speeds and, accordingly, the vehicle was tested with the bonnet in the raised position. Test results of the protection offered to the head of a struck pedestrian were almost all good or adequate. The protection provided by the bumper to pedestrians' legs was predominantly marginal or adequate. Protection of the pelvis was mixed, with areas of good and poor performance. Audi PreSense City is capable of pedestrian detection. In tests of this functionality, the system performed well, impact with the target being avoided in the great majority of cases.
- Buona
- Adeguata
- Marginale
- Scarsa
- Insufficiente
Nome sistema | Speed Limiter |
Funzione informazione limiti velocità | N/A |
Funzione di avviso | Active braking (no warning necessary) |
Funzione limitazione velocità | Manually set (accurate to 5km/h) |
Si applica a | All seats | ||
Attenzione | Sedile conducente | passeggero(i) anteriore(i) | passeggero(i) posteriore(i) |
Visivo | |||
Acustico | |||
|
Nome sistema | Audi PreSense City | |||
Tipo | Forward Collision Warning with Auto-Brake | |||
Operativo da | 10 km/h | |||
Ulteriori informazioni | Default On; Supplementary Warning | |||
Prestazioni | | ||||
Solo funzione freno automatico | il conducente reagisce all'avviso | |||
Velocità operativa | 10-85 km/h | 30-250 km/h | ||
avvicinamento a un veicolo fermo | Vedere AEB urbano | Impatto evitato fino a 50 km/h.Velocità impatto ridotta fino a 80 km/h. | ||
avvicinamento a un veicolo più lento | Impatto evitato fino a 70 km/h. | Impatto evitato fino a 75 km/h.Velocità impatto ridotta fino a 80 km/h. | ||
Guida dietro un'auto a breve distanza | ||||
l'auto antistante frena gradualmente | Evitamento | Evitamento | ||
l'auto antistante frena bruscamente | Mitigazione | Mitigazione | ||
Guida dietro un'auto a lunga distanza | ||||
l'auto antistante frena gradualmente | Mitigazione | Mitigazione | ||
l'auto antistante frena bruscamente | Mitigazione | Evitamento |
The Q5 has a seatbelt reminder system for the front and rear seats. Audi PreSense City is also standard and tests of its performance at highway speeds demonstrated good performance, impact being avoided or mitigated over the entire range of test speeds. A driver-set speed limiter is fitted as standard equipment. A lane support system is available as an option but was not included in this assessment.
- Specifiche
- Dotazione di sicurezza
- Video
- Validità della valutazione
Specifiche
Modello testato Audi Q5 2.0 TDI S tronic (140 kW), LHD
Tipo carrozzeria - 5 door SUV
Anno di costruzione 2017
Peso a vuoto 1805kg
VIN a cui si riferisce la valutazione - all Q5s including Sportback
Classe Grande SUV
Dotazione di sicurezza
Nota: altre dotazioni possono essere disponibili sul veicolo ma non sono state considerate nell'anno del test.
Montato di serie sul veicolo
Montato sul veicolo come parte del Safety Pack
Non montato sulla vettura testata ma disponibile come opzione o come parte del Safety Pack
Non disponibile
Non applicabile
Video
Validità della valutazione














Ulteriori informazioni nella sezione Commenti generali della valutazione

The passenger compartment of the Q5 remained stable in the frontal impact. Dummy readings indicated good protection of the knees and femurs of both the driver and passenger. Audi demonstrated that a similar level of protection would be provided to occupants of different sizes and to those sat in different positions. All critical body regions of the passenger dummy were well protected. In the full-width rigid barrier test, protection of all body regions was good, with the exception of the chest of both dummies and the neck of the rear passenger dummy, protection of which was adequate. Tests on the front seats and head restraints demonstrated good protection against whiplash injury in the event of a rear-end collision. A geometric assessment of the rear seats also indicated good whiplash protection. The Q5 has, as standard equipment in Europe, Audi PreSense City, an autonomous emergency braking system. In tests at low speeds, typical of city driving, where many whiplash injuries are caused, the system performed well, avoiding collision with the target at all but the highest test speed.
